| 型號 Model | 抽速 Ultimate Pressure (50/60Hz) | 極限壓力 UItimate Pressure(50/60Hz) | 功 率 Power (50/60Hz) kW | 轉(zhuǎn)速 Speed (50/60 Hz) RPM | 進(jìn)氣口徑 InletDiameter （mm） | 出氣口徑OutletCaliber （mm） | 齒輪腔量 Gear CavityVolume（L） | 冷卻水量 Caoling Water Volume | 重量Weight （kg） | |||||
| m/Hr | L/min | L/S | mbar | Torr | Pa | L/min | gal/min | |||||||
| BLZ50 | 180/216 | 3000/3600 | 50/60 | 0.02 / 0.01 | 0.015 / 0.0075 | 2 | 7.5/7.5 | 2900 / 3550 | 65 | 40 | 0.85 | 2.50 | 0.67 | 295 |
| BLZ70 | 250/300 | 4200/5000 | 70/84 | 7.5/7.5 | 80 | 40 | 0.85 | 2.60 | 0.70 | 350 | ||||
| BLZ110 | 400/480 | 6600/7920 | 110/132 | 11/15 | 100 | 65 | 1.40 | 2.80 | 0.75 | 480 | ||||
| BLZ150 | 540/650 | 9000/10800 | 150/180 | 18.5/18.5 | 150 | 65 | 2.00 | 3.00 | 0.80 | 520 | ||||
| BLZ200 | 720/850 | 2000/14400 | 200/240 | 22/22 | 150 | 65 | 2.00 | 4.00 | 1.07 | 680 | ||||
| BLZ70PM | 250/300 | 4200/5000 | 70/84 | 5.5/7.5 | 65 | 40 | 0.85 | 2.50 | 0.67 | 295 | ||||
| BLZ110PM | 400/480 | 6600/7920 | 110/132 | 7.5/11 | 80 | 40 | 0.85 | 2.50 | 0.67 | 350 | ||||
| BLZ160PM | 580/700 | 9600/11500 | 160/192 | 11/15 | 100 | 65 | 1.40 | 2.60 | 0.70 | 480 | ||||
| BLZ220PM | 800/960 | 13200/15800 | 220/264 | 15/18.5 | 150 | 65 | 2.00 | 2.80 | 0.75 | 520 | ||||
| BLZ330PM | 1200/1440 | 9800/23700 | 330/396 | 22/22 | 150 | 65 | 2.00 | 3.50 | 0.94 | 680 | ||||
| BLZ300PM | 1080/1290 | 8000/21600 | 300/360 | 0.5/0.3 | 0.38/0.22 | 50/30 | 18.5/18.5 | 150 | 65 | 2.00 | 2.80 | 0.75 | 520 | |
